3 Core Rubber Submersible Flat Cable

3 Core Rubber Submersible Flat Cable

Category:

– Operating Temperature:- -10°C to max. +90°C
– Nominal voltage:- 1.1 KV
– Test voltage:- 3.0 KV
– Bending radius:– 6 X cable diameter

– DIN VDE 0281 part 810,
– IEC 245 & BS 6007, BS 6899
– Conductor:- Bare bunch copper IS: 8130
– Insulation:– ERP Rubber
– Outer sheath:– ERP Rubber

– Temperature range -40°C To +90°C
– Exceptional long term performance
– Excellent impact resistance
– Excellent weather resistance

– Ideal for irrigation pump,
– Drinking water supply pumps,
– Submersible pump motor power supply

– As per IS : 694:2010:– Red, yellow, blue
– As per IEC:60227:– Black, light blue , brown

3 CORE RUBBER SUBMERSIBLE FLAT CABLE
3 core flat cable
